Origin: Suizhou China
Brand: CLW
Emission standard: EURO 2/3/4/5/6
Steering wheel: LHD/RHD
Chassis: Isuzu/ Sinotruck/Shacman/Dongfeng/CLW/JAC/Foton/JMC
+86 13329890945
+86 19813830308
+86 13329890945
+86 19813830308
Parameters of the 4.5m3 garbage compactor truck:
GVW | 4495kg | truck body volume | 4.5m3 |
rated loading capacity | 400kg | outer diameter | 5995X2090X2450mm |
curb weight | 3965kg | passengers | 2 |
approach/ departure angle | 20/10° | front/ rear suspension | 1130/1710mm |
axle loading capacity | 1617/2878kg | max speed | 105km/h |
garbage compactor truck chassis parameters | |||
brand | FOTON | axle number | 2 |
wheelbase | 2850mm | tyre size | 6 |
tyre number | 6.50R16LT 10PR | fuel type | diesel |
emission standard | EURO VI | engine power | 85Kw |
4.5m3 garbage compactor truck body parameters:
volume | 4.5m3 | body shape a | arc-shape |
body thickness | side plate 3mm bottom plate 4mm | rear loader effective volume | ≥0.6m³ |
garbage loading cycling time | ≤18s | discharge time | ≤35s |
control method | manual + automatic | hydraulic system max pressure | 18MPa |
