Origin: Suizhou China
Brand: CLW
Emission standard: EURO 2/3/4/5/6
Steering wheel: LHD/RHD
Chassis: Isuzu/ Sinotruck/Shacman/Dongfeng/CLW/JAC/Foton/JMC
+86 13329890945
+86 19813830308
+86 13329890945
+86 19813830308
Parameters of the 12m3 garbage compactor truck
GVW | 18000kg | tank body volume | 10~12m3 |
retad loading capacity | 7370kg | curb weight | 10500kg |
passengers | 2 | approach/departure angle | 19/11° |
axle number | 2 | wheelbase | 3950mm |
axle loading capacity | 6500/11500kg | max speed | 105km/h |
Parameters of the garbage compactor truck chassis | |||
chassis model | Q1185LJ9CDE | chassis type | II |
tyre number | 6 | fuel type | diesel |
tyre size | 10.00R20 | emission standard | EURO 6 |
engine power | 169Kw | displacement | 6200ml |
Parameters of the garbage compactor truck body
body volume | 12m3 | body shape | arc-shape |
body material | side plate 4mm buttom plate 5mm | rear loader volume | 1.2m3 |
loading one time cycling time | 25s | discharging time | 45s |
control method | manual+ automatic | max pressre | 18Mpa |
